We are an architectural graphics studio specialising in Revit graphics and solutions for architects + design professionals.

We have created graphic Revit templates, BIM solutions + tools specifically for small to medium architecture studios.

BIM . . . BUT BETTER

At Project by n, our objective is to help architecture practices create beautiful drawings in Revit while achieving efficiencies in the production of drawing information and in the delivery projects from conception through to final realization. As architects ourselves, we have experience in working with architecture and design studios that share our passion for producing beautiful graphic drawing output and imagery. In our work, we employ a methodology that focuses on the production of exemplar graphic output and the implementation of efficient work-flows for the effective organization of drawing information, graphic tools, annotations, schedules, views and sheets.

We have created a Revit template specifically developed for design-led architecture studios with a focus on crafted design output. It is designed to help you organise your drawings, sheets and views more easily navigate the Revit browser. The template is fully set up with graphic features, annotations and elements that will greatly enhance the graphic output from Revit to create beautiful, quality drawings.

THE CHALLENGE

THE CHALLENGE

The benefits of BIM are invaluable to construction design professionals and this work process is fast becoming a keystone of the industry. Upgrading to this new way of working, can be a daunting experience, presenting graphical and work-flow challenges. Here is where we can help.

THE SOLUTION

THE SOLUTION

We have developed a suite of tools and products to simplify and streamline the implementation of BIM workflows and Revit software into your practice. Our tools will equip you with the fundamental, key elements for organizing and producing finely crafted output in Revit.

THE BENEFITS

THE BENEFITS

Our template will equip you the tools to master the production of graphically elegant drawing output from Revit. The integrated features, graphic standards and components have been designed to save you considerable time, money and effort in setting up and getting started in Revit.

create beautiful Revit graphics
with our architectural designed template

TEMPLATE

TEMPLATE

REVIT TEMPLATE

Our Revit template is designed to economise your time, money and efforts in setting up Revit graphics and will streamline the process of implementing Revit into your design practice.

The integrated features of the template will equip you with the tools to get a head start in mastering Revit and in creating graphically elegant drawing output, even as a beginner.  Our template can be quickly and easily adapted, updated and tweaked to add any graphic elements specific to your architecture studio and standards.

DOMESTIC PROJECTS

DOMESTIC PROJECTS

We have developed our Revit Graphic Template to be hightly effective in manageing the drawing information and graphic output for large scale, multi-unit residential schemes and apartment buildings.

RESIDENTIAL DEVELOPMENTS

RESIDENTIAL DEVELOPMENTS

We have developed our Revit Graphic Template to be hightly effective in manageing the drawing information and graphic output for large scale, multi-unit residential schemes and apartment buildings.

COMMERCIAL DEVELOPMENTS

COMMERCIAL DEVELOPMENTS

Our Revit graphic template is built to be used in medium to large scale commercial projects including multi-story office buildings, industrial developments and retail units.

OUR FREE TEMPLATE GUIDE

Our free template guide showcases the features of our Revit graphic template and sets out the guidelines for its use in a simple step by step process. It provides detailed descriptions of the functions of our integrated view templates, parametric annotations and graphic elements. It also outlines tips for how to adapt the template to your design practice standards where you may wish.

The manual can be used as a studio technical standard for Revit within your practice and as a resource for best practices + guidelines in the development of drawing output from Revit.

download our free template guide

FEATURES

FEATURES

Beautiful drawings from Revit…?

It’s possible with the right tools.

REVIT GRAPHIC TEMPLATE : FEATURES

DRAWING ORGANISATION

We have carefully constructed the template browser to optimize the efficiency of your workflow while adhering to industry standards for working in Revit. It is designed to be simple and organized in order to help you easily navigate through sheets and views as your project evolves from concept through to construction stages of a project.

LINE WEIGHTS + HATCHES

Clean and considered line weights are key to achieving beautiful drawings. For this reason, having carried out many tests and trials, we have curated a set of essential line weights for inclusion in our template.

Our library of hatches and filled regions will give you more graphic control over your drawings and to produce the best quality output from Revit. Chooses between 15 custom made filled region hatch patterns to enhance your drawings.

GRAPHIC VIEW TEMPLATE

We have carefully designed custom view templates that work seamlessly with the template to quickly and automatically change the view settings of plans, sections, elevations, 3D views and detail views. Our view templates are based on industry standards for the representation of architectural drawings and details.

TITLE BLOCK + DRAWING SHEETS

Our template title blocks come in A4, A3, A2 and A1 sizes and are easy to customize to suit your practice standards. They have a range of integrated parameters that work with the template and project browser to easily categorise each drawing. The integrated parametric scale bars and north sign allow changes to be made to individual sheets simply and swiftly from with your project.

TEXT STYLES

As architects we know the importantance of having a range of text styles and sizes for annotating architectural drawings of varing types and scales. Our custom text styles therefore come in a large selection of sizes, colours and transparencies to suit a wide range of applications. Each text style follows a standard naming convention such that they are neatly organised in the template and that their appearance, size and colour easily identifiable.

ANNOTATIONS

We have modified and expanded the range of tags available in the default Revit template such that there is a full set of graphic tags available to our template users to enhance the legibility of drawings. We have also curated a suite of customised dimension annotations suitable for a variety of different applications.

PRODUCTS

PRODUCTS

BEST PRACTICE GUIDE

BEST PRACTICE GUIDE

Download our free Best Practices PDF with tips and guidelines on how to maintain the health and performance of your REVIT models.

REVIT TEMPLATE

REVIT TEMPLATE

Our Revit graphic template file compatable with Revit 2018, 2019, 2020 + 2021. Purchase and download the template here.

SAMPLE PROJECT

SAMPLE PROJECT

See how the template is put in practice with our full sample project complete with general arrangment drawings and details using our graphic template.

Payment for our products is simple.

We accept all credit cards and Paypal. You will receive a link to
your email to download your purchases.
